Kinds of Jib Cranes
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is attached to a pivoting vertical member and up to 20 feet long. Jib cranes are able to transport loads between any areas within the boom's arc of rotation. Light duty units are utilized within factories and warehouses for loads weighing up to 5 tons. The BestJibCranes.com web site features the major kinds of jib cranes as being either wall-mounted, mast mounted or free-standing.
Free Standing
The free-standing jib crane models do not need any support from the building structure and could stand by themselves. The horizontal boom in this particular case is connected to a pivoting vertical column that is anchored solidly to the building floor. This type of jib crane could rotate a full 360 degrees and requires a foundation made of either steel or concrete.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom which are connected to the floor of the building and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the benefit of not needing the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom which is connected to the building wall rather than the normal vertical column. These machine are ideal in places where the full 360 degree rotation is not needed and offer up to 200 degrees of rotation.
Depending on how the boom is supported, there are two model varieties. One kind uses a tie rod from above the boom that is connected to the wall. The other variety supports the boom from below by using a cantilever brace which is attached to the wall also.
