Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in making in manufacturing construction equipment. Machines like manlifts, boom lifts and aerial lifts. These types of machines are designed to facilitate access to places that are hard to reach, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and includes handholds or platforms or steps which are connected to the unit to be able to transport personnel from every floor.
TB85
The Terex TB85 provides a maximum working height of 91 feet. Moreover, the platform's maximum height reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle above horizontal measuring 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 9 feet high by 8 feet, 1 1/2 inches wide by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall reaches 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 provides a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
